Vortex

Vortex

Suction and pressure performance at the highest level

The Amphitec Vortex is a versatile, powerful pressure/suction trolley for industrial applications. It impresses with its high suction power, precise pressure delivery and flexibility in handling dry and wet materials – even over long distances.

  • Suction and blowing with one system
  • Transport of liquid and solid materials by means of air flow
  • Robust Roots blower with variable power control

The pump

Variable performance thanks to intelligent vacuum technology

The Vortex is equipped with a Roots blower whose power can be infinitely adjusted to suit the material to be vacuumed. A reinforced version with up to 96 % vacuum is available for particularly heavy materials.

  • Infinitely variable Roots blower
  • Pressure conveying (blowing) via hoses or pipes

The container

  • Tiltable for easy emptying
  • Automatic filter cleaning
  • Suction and pressure discharge via the same system

The articulated hose carrier

  • Swivels by means of a robust worm gear
  • Up to 210° movement radius
  • Precise alignment of the radio remote control
  • Various adaptable nozzles

Applications

Suitable for all industrial suction and pressure applications
  • Suction of sludge, dust, granulates and liquids
  • Return of materials via compressed air
  • Use in chemical plants, power stations, steelworks, silos, tanks
  • Cleaning, maintenance or product transportation on factory premises
  • Optional ATEX extension for potentially explosive atmospheres

Technical data

Download brochure "Vortex"

Note: The technical data given corresponds to the example model shown here. Individual values may vary depending on customer requirements and equipment. Please contact us for a configuration tailored to your project.

Container

  • Material: Stainless steel
  • Max. Capacity: 14 m³
  • Tilt direction: to the rear
  • Tilt angle: 50°
  • Height of the tilting edge: approx. 2,250 mm thanks to the Hi-Lift system
  • Filter area: 55 m²

Suction

  • Max. volume flow Roots blower: 11,000 m³/h
  • max. vacuum capacity: 96%


Blow out

  • Max. volume flow Roots blower: 2,500 m³/h
  • max. operating pressure: 1 bar

Water system

  • Water pump drive: hydraulic
  • Operating pressure: 120 bar
  • Volume flow: 50 l/min
  • Hose length: 18 m
  • Water tank: 400 l

Equipment

  • Articulated hose carrier: 8′ suction hose
  • Air compressor: 3 m³/min / 7 bar
  • Hydrostatic drive: OMSI Hydrostatic Drive
  • Hi-Lift system: unloading into containers or
    big bags possible
  • Fill level indicator: 1x in the tank, 1x in the filter chamber
  • Unloading aids: 2x pneumatic vibrators on the container and in the filter chamber
  • Hose storage: left side, stainless steel, transport box 5 m
  • Tool box: right-hand side (rear), stainless steel
  • Radio remote control: Type M, two-hand operation
  • Earthing system: with 20 m cable reel
  • SIR version: ATEX system available for operation in Zone 21 & 22 (Cat. 2D)
